DM02 tilting quick hitch

DM02 tilting quick hitch

Experts recommend：

METDEEM Tilting quick hitch is a fully automatic double safety quick coupler. In addition to helping the excavator operator to realize the automatic and fast switching of various attachments such as buckets and breakers in the cab, it can also be 90° left and right, and one direction the maximum 180° tilting bucket can realize excavation in unconventional positions such as under the pipe and at the root of the wall, expand the working range of the machine, save time and improve work efficiency.

Chat Now

Chat Now

Main features of METDEEM Tilting quick hitch

1.Tilt cylinder with higher torque, safety design.

Full-automatic Double locking.
Extra high strength steelis used throughout body.
Variable pin centre design.
With a tilt angle of 0-180° for DM00-DM04, 0-140° for DM06-DM08.

6.Original Japan switch.

7.All spare parts ready for installation ( pins, pipes, solenoid valve, switch, wire harness, manual, kit,bolts and nuts etc).

METDEEM brand excavator tilt hitch makes your excavator attachments have instant tilt capability, which can be completely tilted 90 degrees in two directions, suitable for excavators from 0.8 tons to 25 tons.

Tilting Quick Hitch Coupler
Category/Model	DM-00	DM-01	DM-02A/B	DM-02B	DM-04A	DM-04B	DM-06	DM-08A/B
Tilt Degree	180°	180°	180°	180°	180°	180°	140°	140°
Drive Torque	930 NM	2870 NM	4400 NM	4400 NM	4400 NM	7490 NM	10623 NM	18600 NM
Tilt Displacement	0.627 L/MN	0.627 L/MN	1.016 L/MN	1.016 L/MN	1.016 L/MN	1.896 L/MN	2.3 L/MN	3.62 L/MN
Tilt Working Pressure	210 bar	210 bar	210 bar	210 bar	210 bar	210 bar	210 bar	210 bar
Tilt Necessary Flow	2-4 Lpm	5-16 Lpm	5-16 Lpm	5-16 Lpm	5-16 Lpm	15-44 Lpm	19-58 Lpm	35-105 Lpm
Quick Coupler Working Pressure	25-300 bar	25-300 bar	25-300 bar	25-300 bar	25-300 bar	25-300 bar	25-300 bar	25-300 bar
Necessary Flow	15-25 Lpm	15-25 Lpm	15-25 Lpm	15-25 Lpm	15-25 Lpm	15-25 Lpm	15-25 Lpm	15-25 Lpm
Excavator	0.8-1.5 Ton	2-3.5 Ton	4-6 Ton	4-6 Ton	7-9 Ton	7-9 Ton	10-16 Ton	16-22Ton
Overall Dimension (L2W1H1mm)	370280442	477280567	518310585	545310585	541350608	582350649	720450784	858500911
Weight	55 Kg	112 Kg	156 Kg	156 Kg	170 Kg	208 Kg	413 Kg	570/655 Kg

Our Services

1.We can offer a comprehensive range of quick hitch, tilt hitch, excavator tilt hitch, hydraulic quick coupler, power tilt hitch, etc…

You may rest assured that all of our products can be supplied in a wide range of designs, and the product can be customized according to your personalized requirements. Meanwhile, we can offer an excellent after-sale service.
We will keep your business information confidential.
We promise to reply to you upon receipt of your inquiry within 12 hours.
The order will be produced exactly according to your detailed requirements and bucket dimensions. Each attachment will be tested before delivery. Our QC will submit the inspection report before shipment.
6. OEM/ODM，Offer your design documents or tell us your ideas and our R&D team will do the rest.

Warranty

METDEEM tilt hitchs are guaranteed against failure due to defective design, materials, or workmanship for a period of one year or 2,000 hours. Within the first 6 months, we offer a free replacement service.
