METDEEM High Quality Wholesale DM210 Hydraulic Breaker Side Type for CAT SANY Excavator

METDEEM High Quality Wholesale DM210 Hydraulic Breaker Side Type for CAT SANY Excavator

Experts recommend：

Brand–METDEEM
Origin–Yantai, Shandong Province, China.
Model–Hydraulic Breaker Side Type
Size–Diameter of the chisel is 210mm.
Standard–CE certification.
Payment method–International trade Payment methods such as letters of credit are supported.
Supply capacity–Possessing the customized production capacity for high-end large-scale breakers.
Core advantages–The flagship breaker for 70-ton class excavators, with a top-notch impact force of 33,900 joules and a stable and reliable high-pressure system, is the ultimate choice for those pursuing ultimate crushing efficiency and equipment reliability.

Chat Now

Chat Now

Core advantages and Highlights of the Product

Precisely matched with high-performance 60-70-ton class excavators
With an impact energy of up to 33,900 joules, it is specially optimized for modern high-flow and high-pressure 60-70-ton class high-end excavators.
It can fully leverage the hydraulic power of the main unit and achieve ultimate efficiency in hard rock crushing and the disintegration of giant concrete structures.
Stability and reliability under high pressure
The working pressure is set in the high-pressure range of 250-270 bar.
The hydraulic system components (such as seals and valve cores) are all selected from top Brands and specially matched to ensure no leakage or attenuation during long-term operation under high pressure, and the impact force remains consistent.
The crystallization of top-notch manufacturing craftsmanship
It represents the highest manufacturing standard of our Hydraulic Breaker Side Type
From material selection, heat treatment to precise assembly, every step is pursued with the utmost care, aiming to create a flagship product that can handle the most extreme working conditions and has an extremely long maintenance interval.

METDEEM brand Hydraulic Breakers is recognized by global customers because of its high performance in safety and durability.

Product Model Parameters

Compatible excavator tonnage–60-70 tons
Working weight–8,200 kilograms
Required oil flow rate–300-350 liters per minute
Set pressure–290-310 bar
Working pressure–250-270 bar
Impact energy–33,900 joules
Impact frequency–110-150 times per minute
Oil pipe diameter–1-1/4 inch
Noise level–125 decibels
Diameter of the chisel–210 millimeters

Factory Strength – Global Delivery

Service：
We offer a comprehensive “Digital Product Information Package”, which includes high-definition product videos of DM210, PDF versions of 3D explosion images, interactive electronic manuals, and a frequently asked questions library.
You can obtain the information you need anytime and anywhere. Our online engineer team provides real-time answers to your questions.

After-sales warranty：
We implement a 12 month warranty policy.
Based on the R&D and testing data of our country’s high-tech enterprises, we provide confidence guarantee for the key structural components of DM210.
The accessory catalogue is clear, the quotations are transparent, and it supports customers to maintain it independently or through authorized Service points.

OEM&ODM：
With a strong R&D team and industry experience, we can provide ODM Services for the DM210 platform to capable partners, jointly developing variant products that meet specific market regulations or performance requirements.

Compatible Brand excavators：
Specialized research has been conducted for top-tier 70-ton Models such as Caterpillar 390, Liebherr R 938, and Komatsu PC700.
We can provide installation and commissioning parameter suggestion tables based on extensive practical experience summaries to help customers quickly complete equipment matching.

Factory Qualifications：
Our factory has gathered high-quality talents with rich industry experience and possesses unique skills in the assembly and debugging of large breakers.
Each DM210 undergoes a final pressure test and no-load test to ensure that its performance meets the standards before leaving the factory.
