Experts recommend：

Brand-– METDEEM.
Origin– Yantai, Shandong Province, China.
Model— Top type breaker DM175.
Size— The Diameter of the chisel is 175mm.
Standard— CE certification.
Payment method— We accept complex contracts and payment arrangements that comply with international Standards.
Supply capacity— It represents the highest manufacturing level of our factory’s Top type breakerseries and supports customization for high-end projects.
Core advantages–Top-grade intelligent engineering right-angle hammer, with adjustable frequency output of 12202 joules, combines great power with ultimate flexibility, specially designed for fine crushing projects in super tunnels, water conservancy hubs and complex mines.

Chat Now

Chat Now

Core advantages and Highlights of the Product：

- The top balance of performance and flexibility
  With an Impact energy of 12,202 joules, it provides nearly the crushing force of a large hammer for 35-40 ton class equipment while retaining the core flexibility of a right-angle hammer.
  It is the ultimate tool for handling tunnel sections, large chambers, high and steep slopes and other projects that require both force and Angle.
- Intelligent frequency modulation function
  Equipped with an external displacement directional valve and a hydraulic frequency modulation valve, users can continuously adjust the striking frequency within the range of 250-350 times per minute according to the hardness of the rock and the crushing requirements.
  In soft rock, it can increase speed and efficiency; in hard rock, it can reduce frequency and increase force, achieving the optimal adaptation of one machine.
- The top-level structure designed for compound working conditions
  Its structural design simultaneously meets the load-bearing capacity of vertical impact, torsional resistance to lateral breakage, and fatigue strength requirements for frequent Angle changes, representing the peak of design and manufacturing of right-angle hammers in heavy engineering applications.

METDEEM brand Hydraulic Breakers is recognized by global customers because of its high performance in safety and durability.

Product Model Parameters：

Compatible excavator tonnage–35-40 tons
Working weight–4,390 kilograms
Required oil flow rate–210-290 liters per minute
Set pressure–260-280 bar
Working pressure–180-200 bar
Impact energy–12,202 joules
Impact frequency–250-350 times per minute
Oil pipe diameter–1-1/4 inch
Noise level–125 decibels
Diameter of the chisel–175 millimeters

Factory Strength – Global Delivery–Integrated&Open Type

Service
We have developed an interactive online tool called “Device Frequency Modulation Guide”. Customers input the basic rock type or working condition description.
This tool can provide suggestions for the starting setting of the DM175 frequency modulation valve and offer further refined adjustment guidance through the online customer service.
After-sales warranty
Metdeem warranty period is 12 months,meet the after-sales service demands of customers.
For the complex hydraulic control system of DM175, we offer a “Control System Maintenance Package”, which includes recommended filter replacement cycles, hydraulic oil cleanliness Standards, and key points for valve core inspection, to assist customers in conducting scientific preventive maintenance.
OEM&ODM
We can provide “technical joint calibration” services for DM175 to customers with strong brand influence.
According to the recommended working condition parameters, we can customize the equipment before it leaves the factory, making it more in line with the usage habits of the customer group.
Compatible brand excavators
Deeply compatible with 40-ton flagship Models such as Caterpillar 349, Komatsu PC400, and Volvo EC480.
We constantly collect on-site matching data and continuously optimize the collaborative working performance of our products with Models of various brands.
Factory qualifications
Our “utility Model patent” technology is comprehensively reflected in the DM175, especially in the rapid response structure of its external displacement directional control valve and the precise control of the frequency modulation valve.
These patented technologies ensure the reliability and durability of the equipment under advanced functions.
